| Approval | CE, UKCA, cULus Listed, FCC, IC, TÜV |
| Sensor principle | Transponder |
| Coding level to ISO 14119 | Low |
| Classification to EN 60947-5-3 | PDDB |
| Transponder coding | coded |
| Reset type | Power reset |
| Suitable for series connection | no |
| unit type | Sensor |
| Supply voltage (V) | 24 V |
| Type of supply voltage U1 | DC |
| Power consumption DC | 1 W |
| Number of inputs | 2 |
| DC voltage at input | 24 V DC |
| Number of OSSD outputs | 2 |
| Number of sig. outputs | 1 |
| Potential isolation S/C O | No |
| S/C output short circuit proof | Yes |
| Utilisation cat. to EN 60947-1 | DC-13 |
| Ambient temperature standard | EN 60068-2-14 |
| Ambient temperature | 0 – 60 °C |
| Storage temperature standard | EN 60068-2-1/-2 |
| Climatic suitability standard | EN 60068-2-78 |
| Humidity rating | 93 % r. h. at 40 °C |
| EMC to standard … | EN 55011: Class A EN 60947-5-3 EN 61326-3-1 |
| Vibration to standard … | EN 60068-2-6 |
| Acc. shock to standard1 | 30g |
| Overvoltage category | III |
| Pollution degree clear.&creep. | 3 |
| Protection type, housing | |
| UL enclosure type | Type 1 |
| Pulse length lock/unlock req. | 350 – 400 ms |
| Bend radius (when laying) K1 | 5 x Ø |
| Escape release available | No |
| Type 1 actuator | PSEN ml 1.1 |
| Connection type | M12, 8-pin male |
| Cable lines | LiYY 8 x 0.25 mm2 |
| Product material | Zn Aluminium Galvanised steel Plastic Stainless steel |
| Height dimension | 217.2 mm |
| Width dimension | 40 mm |
| Depth dimension | 40 mm |
| Net weight | 950 g |
| Gross weight | 1300 g |
| Operating frequency | 122 kHz – 128 kHz |
