| Product characteristics | |||
|---|---|---|---|
| Electrical design | PNP | ||
| Output function | normally closed | ||
| Sensing range [mm] | 10 | ||
| Housing | threaded type | ||
| Dimensions [mm] | M30 x 1.5 / L = 80 | ||
| Application | |||
| Application | simple evaluation of rotating and linear movement with regard to underspeed; blocking | ||
| Electrical data | |||
| Nominal voltage DC [V] | 10…36 | ||
| Current consumption [mA] | < 20 | ||
| Protection class | III | ||
| Reverse polarity protection | yes | ||
| Outputs | |||
| Total number of outputs | 1 | ||
| Electrical design | PNP | ||
| Output function | normally closed | ||
| Max. voltage drop switching output DC [V] | 2.5 | ||
| Permanent current rating of switching output DC [mA] | 250 | ||
| Short-time current rating of switching output [mA] | 250 | ||
| Short-circuit proof | yes | ||
| Overload protection | yes | ||
| Detection zone | |||
| Sensing range [mm] | 10 | ||
| Sensing range adjustable | no | ||
| Operating distance [mm] | 0…8.1 | ||
| Measuring/setting range | |||
| Setting range [Imp/min] | 5…3600 | ||
| Accuracy / deviations | |||
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3 | ||
| Hysteresis [% of Sr] | 10 | ||
| Response times | |||
| Start-up delay [s] | 5 | ||
| Max. damping frequency [Imp/min] | 18000 | ||
| Software / programming | |||
| Adjustment of the switch point | multiturn potentiometer | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…80 | ||
| Storage temperature [°C] | -25…80 | ||
| Protection | IP 65; IP 67 | ||
| Mechanical data | |||
| Weight [K40] | 303.5 | ||
| Housing | threaded type | ||
| Mounting | flush mountable | ||
| Dimensions [mm] | M30 x 1.5 / L = 80 | ||
| Thread designation | M30 x 1.5 | ||
| Materials | brass special coating; PA; TPE-U | ||
| Tightening torque [Nm] | 50 | ||
| Displays / operating elements | |||
| Display |
| ||
| Accessories | |||
| Accessories (supplied) |
| ||
| Electrical connection | |||
| Connection | Cable: 2 m, PUR; 3 x 0.5 mm² | ||
